URL encoding password reset or email confirmation tokens

asp.net, identity

Thursday, September 29, 2016 9:44:00 AM

Asp.Net Identity 2.0 makes it really easy to validate an email address by using the GenerateEmailConfirmationTokenAsync method. However I recently hit an issue where the simplest path, from the same controller, in the same web app, on the same server could not round trip a validation token to confirm the email address.

Using nancy endpoint to send a code, and then validate the code.

public class ConfirmEmailModule : NancyModule
{
    private readonly IdentityUserManager _userManager;

    public ConfirmEmailModule(IdentityUserManager userManager) : base("confirmEmail")
    {
        _userManager = userManager;
        Get["/", true] = async (x, ct) =>
        {
            var validateAttempt = this.Bind<ValidateEmail>();
            var code = HttpUtility.UrlDecode(validateAttempt.Code);
            var result = await _userManager.ConfirmEmailAsync(Guid.Parse(validateAttempt.UserId), code);

            if (result.Succeeded)
            {
                ViewBag.ReturnUrl = validateAttempt.ReturnUrl;
                return View["EmailValidated"];
            }

            ViewBag.Errors = result.Errors;
            return View["ErrorValidatingEmail"];
        };

        Post["/{userId}", true] = async (x, ct) =>
        {
            var userId = Guid.Parse(x.userId);
            string code = await _userManager.GenerateEmailConfirmationTokenAsync(userId);
            var baseUrl = Context.Request.Url.SiteBase;
            var encodedCode = HttpUtility.UrlEncode(code);

            var callbackUrl = $"{baseUrl}/confirmEmail?userid={userId}&code={encodedCode}";

            await _userManager.SendEmailAsync(userId,
                "Confirm your email address",
                "Please confirm your email address by clicking <a href=\"" + callbackUrl + "\">here</a>");

           return HttpStatusCode.OK;
       };
    }
 }

Using Postman to post a userId to the endpoint to send a confirmation URL created the following confimation code

frsv1AuYKgDTxcomdt27b/xLiGbzg/pv1k9e6X91B8enQUOIQn4sQ6w/vyZZ4QmIqHVHqMtuFXwbtSJoXKByKkTf7pM1EAftRwwJ2z3BZ/g61NLAhJQ5f8y8NcS+b1vR+/4Cs+yni5GiNElTqqtZVj99c1SY+J7Zsp+Ke/YjkVU3Q75eoghFWlZaCnyUAr29

And the URL encoded version to send in the email link becomes

frsv1AuYKgDTxcomdt27b%2FxLiGbzg%2Fpv1k9e6X91B8enQUOIQn4sQ6w%2FvyZZ4QmIqHVHqMtuFXwbtSJoXKByKkTf7pM1EAftRwwJ2z3BZ%2Fg61NLAhJQ5f8y8NcS%2Bb1vR%2B%2F4Cs%2Byni5GiNElTqqtZVj99c1SY%2BJ7Zsp%2BKe%2FYjkVU3Q75eoghFWlZaCnyUAr29

Now after clicking the emailed link, and then URL Decoding the validation code the code that is used for verification becomes

frsv1AuYKgDTxcomdt27b/xLiGbzg/pv1k9e6X91B8enQUOIQn4sQ6w/vyZZ4QmIqHVHqMtuFXwbtSJoXKByKkTf7pM1EAftRwwJ2z3BZ/g61NLAhJQ5f8y8NcS b1vR /4Cs yni5GiNElTqqtZVj99c1SY J7Zsp Ke/YjkVU3Q75eoghFWlZaCnyUAr29

Where all '+' chars in the original code have been replaced with spaces. Therefore there is an issue with directly URL encoding the Base64 string into a percent-encoded URL safe string. Hoever the wikipedia article on Base64 states that there is a URL safe variant of Base64, which does not use the percent encoding. A solution to creating URL safe Base64 string has been provided on Stack Overflow.

Using this sample, we can create a utility to make the Base64 codes URL safe, wihtout needing to generically URL encode a string.

public static class Base64Utility
{
    static readonly char[] padding = { '=' };

    public static string UrlSafeEncode(this string base64String)
    {
        return base64String.TrimEnd(padding).Replace('+', '-').Replace('/', '_');
    }

    public static string UrlSafeDecode(this string urlSafeBase64String)
    {
        string base64String = urlSafeBase64String.Replace('_', '/').Replace('-', '+');
        switch (urlSafeBase64String.Length % 4)
        {
            case 2: base64String += "=="; break;
            case 3: base64String += "="; break;
        }
        return base64String;
    }
 }

By using this encode utility method, the encoded code that is URL safe for the activation link becomes

frsv1AuYKgDTxcomdt27b_xLiGbzg_pv1k9e6X91B8enQUOIQn4sQ6w_vyZZ4QmIqHVHqMtuFXwbtSJoXKByKkTf7pM1EAftRwwJ2z3BZ_g61NLAhJQ5f8y8NcS-b1vR-_4Cs-yni5GiNElTqqtZVj99c1SY-J7Zsp-Ke_YjkVU3Q75eoghFWlZaCnyUAr29

and successfully decodes back to the original code generated by Asp.Net Identiy.
